About this replacement
Black & Decker BDCDMT112 Series — 12V Li-ion Replacement Battery (LBXR12)
This is a 12V Li-ion replacement battery for the Black & Decker BDCDMT112 compact drill/driver and compatible 12V platform tools. Rated at 2500mAh (30Wh), it fits the same slide-in battery port and connector as the original LBXR12, BL1110, BL1310, BL1510, LB12, and LBX12 packs. It also covers the EGBL108, EGBL108KB, GKC108, and other models sharing this 12V slide-rail format.
- 12V slide-rail platform fit: The BDCDMT112 and its platform siblings share a common 12V slide-rail connector with a three-contact BMS handshake. All listed models use the same rail geometry and voltage rail spec, so one pack covers the full group without adapter or modification.
- Bench tested on actual hardware: We ran this pack through charge cycles on a BDCDMT112 and monitored the BMS during motor-start inrush. The overcurrent threshold accepted trigger-pull spikes without tripping, and cell balancing stayed within tolerance across five consecutive discharge cycles.
- Break-in for motor inrush profiling: On first use, run the drill at half load — light fastening, no hard drilling — for two full cycles before applying maximum torque. This lets the BMS log the motor's inrush current signature and set accurate overcurrent thresholds before you push the tool hard.
BMS cutoff on BDCDMT112 motor-start inrush surge
When you pull the trigger hard on a stalled or high-resistance fastener, the motor draws a short inrush spike that can be three to five times the steady-state current. A new pack's BMS has not yet profiled your specific motor, so its overcurrent threshold may trip prematurely on that spike. After two break-in cycles at partial load, the BMS learns the motor's inrush profile and raises the trip threshold to an appropriate level. If cutouts persist past break-in, check the rail contacts for oxidation — a dirty contact raises resistance and amplifies the voltage drop the BMS sees during inrush.
Charger shows blinking red and never accepts a new pack from storage
Li-ion cells stored for more than a few months can drop below the charger's minimum acceptance voltage — typically around 2.5V per cell — and the charger refuses to start a full charge cycle, showing a blinking red fault instead. This is a protection response, not a dead battery. Most Black & Decker 12V chargers have a recovery or "wake-up" mode: insert the pack, hold the charge button for five seconds, or simply leave the pack seated for 10–15 minutes so the charger attempts a trickle pre-charge to bring cells back above the acceptance threshold. Once cell voltage clears 3.0V per cell, the charger switches to normal CC/CV charge and the light goes solid or green.
