Cardio E3 — 14.4V Li-ion Replacement Battery (INR18650-4S1P)
This is a 14.4V 2600mAh lithium-ion replacement battery for the Cardio E3 portable cardiac monitoring device. It matches the OEM part number INR18650-4S1P and fits directly into the E3 battery compartment. Cell voltage, capacity, and connector pinout match the original specification.
- Cardio E3 platform fit: The E3 uses a 4S1P 18650 cell configuration running a 14.4V nominal rail. This battery replicates that architecture exactly — same cell count, same BMS communication protocol, same connector layout. The device firmware reads cell-level data through the BMS, so cell arrangement matters as much as voltage.
- Bench tested on actual hardware: We ran charge and discharge cycles on the E3 platform and confirmed the BMS handshake completes correctly at startup. The protection circuit trips at the expected low-voltage cutoff without triggering a false fault code on the device display.
- Post-installation self-test protocol: After fitting this battery, allow the E3 to complete its full power-on self-test without interrupting the boot sequence. The device BMS runs a verification pass at startup — cutting power mid-sequence logs a battery fault that persists until the next clean reboot, even though the battery is functioning correctly.
Why the Cardio E3 shows a battery fault after a confirmed successful charge
The E3 BMS stores cell chemistry calibration data from the OEM battery and compares it against readings from any new cell during the first few cycles. A freshly installed INR18650-4S1P cell has not yet established its internal resistance baseline in this device, so the BMS flags a chemistry mismatch rather than a hardware fault. This is not a defective battery — it is the BMS learn cycle running as intended. One complete charge-to-discharge cycle resolves the mismatch in most units. If the fault persists after two full cycles, check that the battery connector is fully seated and that cell voltage at rest reads between 14.4V and 16.8V.
Charge indicator stalls below 100% on first charge
On first charge, the E3 charge IC applies a conservative current limit to an unrecognised cell profile, which causes the charge indicator to plateau around 85–95% and stop climbing. This is the charge controller applying a safety ceiling — not a fault with the battery or charger. The cell is still receiving current at a trickle rate even when the indicator appears frozen. Allow the device to remain on charge for a full additional hour past the apparent plateau; the indicator will advance to 100% once the charge IC accepts the new cell's impedance signature.
