About this replacement
Garmin Pro 70 / Pro 550 Trashbreaker — 3.7V Li-ion Replacement Battery (361-00056-09)
This 3.7V, 750mAh Li-ion battery replaces the original pack in the Garmin Pro 70 Trashbreaker, Pro 550 Trashbreaker, and Pro Trashbreaker GPS dog collars. It matches OEM part numbers 361-00056-09, 361-00056-07, and 361-00056-15. The collar powers GPS tracking, remote training signals, and wireless communication — all from this single small cell.
- Trashbreaker collar platform: The Pro 70, Pro 550, and Pro Trashbreaker share the same battery bay dimensions, connector pinout, and BMS handshake protocol. All three draw from the same 3.7V rail, so one cell covers the full collar family without modification.
- Bench tested on actual hardware: We cycled this cell through the collar's full startup sequence — GPS acquisition, radio link to the handheld, and stimulation output. The BMS held charge cutoff at the correct threshold and did not trigger a protection lockout during the radio transmission burst.
- First GPS fix after battery install: After a battery swap, the collar performs a cold start — it has lost its cached satellite almanac. Take the dog outside and keep the collar stationary for up to 10 minutes. Subsequent power cycles will warm-start and reacquire satellites significantly faster.
Why the Trashbreaker collar drains faster in rural or low-signal terrain
In open country with poor GPS satellite geometry or weak radio link to the handheld unit, the collar's GPS receiver increases its sampling rate and the radio transmitter boosts output power to maintain the connection. Both draw more current from the 750mAh cell than they do in clear-sky suburban conditions. Thick tree canopy has the same effect — the GPS chipset works harder to resolve position through foliage. If drain seems abnormal in these environments, it is the collar working correctly, not a battery fault.
Collar not syncing to the handheld after a battery swap
The Pro 70 and Pro 550 handhelds store the collar's device ID in memory, but the collar itself re-registers its radio link on every power cycle. If the collar is powered on before the handheld is ready and scanning, the pairing handshake can fail silently. Power down both units completely, turn the handheld on first and wait for its home screen, then power on the collar. If sync still fails, check that the collar's battery voltage has recovered above 3.5V — a cell below that threshold can complete startup but fail during the radio registration exchange.
