About this replacement
HP Jornada 520 Series — 3.7V Li-ion Replacement Battery (F1798)
This is a 3.7V, 1800mAh Li-ion replacement battery for the HP Jornada 520, 525, 535, and 540 handheld pocket PCs. It replaces OEM part number F1798 and fits the original battery bay without modification. These early-2000s PDAs rely on this cell for all active memory, OS state, and user data — a dead or degraded cell means a device that won't hold anything.
- Jornada 520 series fit: The 520, 525, 535, and 540 share the same battery bay dimensions, connector pinout, and BMS handshake protocol — that's why one cell covers the full line. Voltage tolerance on the BMS is tight at 3.7V nominal, so only Li-ion chemistry works here.
- Bench tested on actual hardware: We ran this cell on a Jornada 520 and confirmed the BMS accepted the charge cycle without fault flags. The protection circuit triggered correctly at low-voltage cutoff and the device read full charge state after a standard charge cycle.
- RAM data protection before swap: Sync all open files to your host PC via ActiveSync before removing the battery. The Jornada holds application state and unsaved data in volatile SRAM powered directly by this cell — cutting power without syncing wipes that data instantly.
Why the Jornada 520 loses all data when the battery dies
Unlike modern smartphones with flash-based storage for app state, the Jornada 520 runs its active memory on SRAM — a volatile memory type that needs continuous power to retain data. When the battery drops below the BMS cutoff voltage, SRAM loses power and clears immediately. There is no background save. Any contacts, calendar entries, or documents stored only on the device and not synced to a PC are gone at that point. Restoring from an ActiveSync backup to a host PC is the only recovery path.
Jornada 520 stuck on boot screen after battery replacement
A replacement Li-ion cell shipped in storage state may arrive at 3.0V or below — below the minimum threshold the Jornada's boot sequence needs to complete. The device powers on, reaches the boot screen, then stalls or resets in a loop. This is not a fault with the battery or the device. Connect the Jornada to its charger and leave it for at least 30 minutes before attempting to boot — the cell needs to reach approximately 3.6V before the system can initialise correctly.
