About this replacement
Impact Medical 754 Eagle Uni-Vent Ventilator — 12V Sealed Lead Acid Replacement Battery (B11152)
This is a 12V, 5000mAh (60Wh) sealed lead-acid replacement battery for the Impact Medical 754 Eagle Uni-Vent Ventilator and 326 Portable Aspirator. It slots into the internal battery bay and provides backup power during transport or mains interruption. Voltage, chemistry, and terminal configuration match OEM part B11152.
- 754 Eagle and 326 Aspirator platform: Both units share the same 12V SLA bay, connector orientation, and BMS handshake protocol — a single cell spec covers the full device family listed under this part number.
- Bench tested on actual hardware: We cycled this cell through the 754's self-test sequence and confirmed the BMS accepted charge, passed the internal resistance check, and released to run mode without a fault code.
- Post-installation self-test protocol: After swapping the cell, allow the ventilator to complete its full power-on self-test without interruption. Cutting power mid-sequence causes the BMS to log a false battery fault that persists until the next clean reboot.
Why the 754 Eagle flags a battery fault on the first charge cycle
The 754's charge IC applies a conservative acceptance threshold tuned to a broken-in OEM cell. A new SLA cell presents slightly higher internal resistance until it completes its first full charge-discharge cycle. The BMS reads this resistance delta as a marginal cell and may not release the fault flag even when the battery reaches full voltage. Running one complete charge-discharge cycle normalises the cell's internal resistance and allows the BMS to pass the threshold on the next startup check.
Charge indicator stalled below 100% after installing a new cell
SLA cells stored before sale develop a surface charge pattern the charge IC doesn't recognise as a fully conditioned cell. The 754's charging circuit responds by capping current early and displaying an incomplete charge state. This is not a cell defect — it clears after one full discharge to approximately 10.5V followed by a slow recharge. After that cycle, the charge indicator tracks correctly and the device passes its pre-transport battery check.
