About this replacement
Lenovo ThinkPad 10 20E3 / 20E4 — 7.5V Li-Polymer Replacement Battery (SB10F46454)
This 7.5V, 4200mAh (31.5Wh) lithium-polymer battery fits the Lenovo ThinkPad 10 2nd generation tablet, including the 20E3 and 20E4 variants. It replaces OEM part numbers SB10F46454, SB10F46455, 00HW016, 00HW017, and 00HW018, among others. If your ThinkPad 10 2nd gen no longer holds charge or fails to power on, this cell is the direct swap.
- ThinkPad 10 2nd Gen platform fit: The 20E3 and 20E4 share the same 7.5V battery rail, connector pinout, and BMS handshake protocol — which is why a single cell covers both model codes. The BMS communicates charge state over the same SMBus lines used in the original Lenovo cell.
- Bench tested on actual hardware: We ran this cell on a ThinkPad 10 20E4 chassis. The BMS accepted the charge handshake on the first cycle, reported voltage correctly to the system board, and did not trigger any firmware-level battery warnings during discharge.
- Fuel gauge recalibration after swap: After fitting this battery, run one full discharge to automatic shutoff, then charge uninterrupted to 100%. This resets the fuel gauge IC calibration against the new cell's actual capacity curve and clears the inaccurate percentage readings that routinely appear after a battery swap on this platform.
ThinkPad 10 2nd Gen shutting down at 15–25% remaining
This tablet draws simultaneous load from the display backlight, WiFi radio, and CPU when in active use — combined, these push current draw high enough to hit a voltage cliff in a degraded or uncalibrated cell. The BMS reads the voltage drop as a critical low and triggers shutdown before the percentage counter reaches zero. With a new cell, this usually resolves after one full recalibration cycle. If it persists, check that the charge IC reached a confirmed 8.40V at the pack terminals at end of charge.
Fast charge not available after battery swap on ThinkPad 10 2nd Gen
The ThinkPad 10 2nd gen negotiates charge rate through the system board's charge IC, not through USB-PD alone. On first installation with a new cell, the charge IC defaults to a conservative rate until it completes one accepted charge cycle and confirms the pack's internal resistance profile. Run one full charge from below 10% to 100% without interruption. After that cycle, the system board re-enables the higher charge rate for subsequent sessions.
