About this replacement
Pure Clean PUCRCX70 — 9.6V LiFePO4 Replacement Battery (GZNF18730HP-3S1P)
This is a 9.6V LiFePO4 replacement battery rated at 1800mAh (17.28Wh) for the Pure Clean PUCRCX70 cordless vacuum cleaner. It replaces OEM part GZNF18730HP-3S1P and restores motor power for floor cleaning and debris collection. LiFePO4 chemistry holds voltage more consistently across a discharge cycle than standard Li-ion.
- PUCRCX70 fit: This battery matches the 9.6V rail and 3S1P cell configuration the PUCRCX70 motor controller expects. The BMS handshake and connector footprint are specific to this model — do not assume other Pure Clean vacuums share this pack.
- Bench tested on actual hardware: We ran this cell under sustained motor load and confirmed the BMS holds within spec. The protection circuit trips correctly on overcurrent and resets without requiring a manual power cycle.
- Dock charging on the PUCRCX70: Do not leave this vacuum on the charging dock permanently. Continuous dock charging on LiFePO4 cells accelerates capacity fade. Charge fully, then remove from the dock and store the vacuum off the charger.
Suction dropping before the battery indicator reaches low
On the PUCRCX70, suction loss mid-session is rarely a dead battery — it is usually motor voltage sag caused by restricted airflow forcing the motor to draw beyond its rated current. A clogged filter is the most common trigger. When airflow is blocked, the motor works harder, pulls more current, and the BMS may reduce output to protect the cell. Clean or replace the filter first, then retest before concluding the battery is at fault.
Motor cuts out on carpet and then recovers after a few seconds
This is a BMS overcurrent trip, not a battery failure. When the vacuum transitions from hard floor to thick carpet, the motor load spikes sharply. If the filter is partially blocked, that spike exceeds the BMS current threshold and the protection circuit shuts output to protect the cell. The pack resets after a short thermal recovery window — usually a few seconds. Clear the filter, check the brushroll for hair wrap, and confirm the pack voltage reads above 9.0V after a full charge.
