About this replacement
Shimpo FG-3000 — 3.6V Ni-MH Replacement Battery (FG-3BAT)
This 3.6V 300mAh Ni-MH battery replaces the FG-3BAT pack in the Shimpo FG-3000 digital force gauge. The FG-3000 is a handheld push/pull measurement instrument used in quality control, inspection, and lab testing. This cell restores full display and measurement function when the original pack no longer holds charge.
- FG-3000 force gauge fit: The FG-3BAT is a compact 30.60 × 31.00 × 11.00mm Ni-MH cell matched to the FG-3000's internal bay dimensions and 3.6V supply rail. The connector and BMS communication profile align with the gauge's charge management circuit — no modification needed.
- Bench tested on actual hardware: We ran this pack through the FG-3000's charge cycle and confirmed BMS handshake, stable voltage delivery under measurement load, and correct low-battery threshold triggering on the display.
- Calibration cycle before field use: After fitting this battery, run a full calibration cycle through the FG-3000's instrument menu before taking measurements. The gauge maps battery state during calibration — skipping this step causes premature low-battery warnings during your first measurement session.
FG-3000 BMS lockout after the gauge sat unused in a carry case for months
Ni-MH cells self-discharge slowly even when the instrument is off. If the FG-3000 sits unused long enough, the pack drops below the BMS recovery threshold and the gauge will not power on or accept a charge. Connect the gauge to its charger and leave it for 30–60 minutes — the BMS needs to see a trickle input before it opens the charge circuit. If the original pack has been in storage more than six months, recovery is often not possible and replacement is the faster path.
Readings resetting or dropping to zero mid-logging session
This happens when sustained sensor load pulls the cell voltage below the FG-3000's operating floor — not a full shutdown, but a momentary dropout that resets the active reading. A worn cell holds its resting voltage but collapses under load. A fresh FG-3BAT pack at 3.6V holds the supply rail steady through a continuous logging run. After fitting the replacement, confirm resting voltage reads at or above 3.6V before starting a logged session.
